Pin #31 (/WE) in AT29C010A/020A/040A must be connect to pin #24 (/OE) when work in SNES EPROM-Cart's (this connection is not required when AT29CxxxA work in NES Dev-cart's)

M27C322 2MB-16bit / 4MB-8bit EPROM pinout (DIP42 pin)

M27C322 2MB-16bit / 4MB-8bit EPROM pinout (only small SO44 or TSOP48 type!)

M27C160 1MB-16bit / 2MB-8bit EPROM pinout (DIP42)

M27C800 512KB-16bit / 1MB-8bit EPROM pinout (DIP42)

M27C400 256KB-16bit / 512KB-8bit EPROM pinout (DIP40)

29F032 4MB-8bit FLASH pinout (SO44)

29F032 4MB-8bit FLASH pinout (TSOP40)

28F160 1MB-16bit / 2MB-8bit FLASH pinout (TSOP48)

28F640 4MB-16bit / 8MB-8bit FLASH pinout (SSOP56)

***
